aluminium clamped pilot ladder

Link Copied
2,450.00 / Meter( + 12% GST applicable)
Business Type Manufacturer, Supplier, Retailer, Trader, Distributor, Importer
Number Of Step Depends On Length
Brand Name Aarav
Finishing Polished
Click to view more

Product Details

Color
Brown
Condition
New
Application
MARINE SAFETY
Feature
Durable, Eco Friendly, Fine Finishing, Foldable, Heavy Weght Capacity, Non Breakable
Pilot Ladder – Aluminium Clamped
232003
Pilot Ladder – Aluminium Clamped (Extended Variant)
232008
Clamping System
Aluminium mechanical clamping at step joints for enhanced grip & strength
Step Materia
Hardwood, synthetic resin, or anti-slip composite (model-dependent)
Side Ropes
Manila or polyester (minimum 20 mm dia.), hand-spliced, UV-resistant
Step Spacing
310 mm (±5 mm) center-to-center, per IMO standard
Step Width
115 mm minimum (non-slip surface)
Certification
IDLR Form 5 approved, meets SOLAS / ISO 799 / IMO A.1045(27) requirements
Length Options
Fully customizable (number of steps as required)
End Fittings
Chock-fastened rope eyes or thimble ends for secure deck fixing
Usage Rating
Suitable for personnel up to 150 kg per rung load
Port
MUMBAI
Payment Terms
T/T
Delivery Time
1 DAY

Aarav Enterprise, Leading Manufacturer Pilot Ladder & Embarkation Ladder in Mumbai

Key Features & Benefits

  • 🔩 Aluminium Clamped Structure – Provides enhanced strength, step alignment, and longevity.

  • 📏 Fully Customizable Build – Designed to match vessel freeboard height and user specifications.

  • Certified & Compliant – Built in accordance with international maritime boarding safety standards.

  • 🛡️ Anti-Slip, Safe Access – Features non-skid steps and firm rope tensioning for safe footing.

  • Corrosion-Resistant Components – Ideal for harsh saltwater environments and long-term use.

  • 🔧 Easy Handling & Storage – Lightweight and designed for efficient deployment, retraction, and stowage.

🚢 Ideal Applications

  • Ship-to-Ship Boarding – For safe transfer of pilots or personnel between vessels at sea.

  • 🛥️ Offshore Platforms & FPSOs – Provides access for inspectors, technicians, or emergency teams.

  • 🏗️ Port & Dockside Operations – Reliable solution for fixed and floating terminal crew access.

  • 🚨 Rescue & Emergency Use – Suitable for lifeboat stations, emergency escape, and retrieval missions.
